Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment

  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment
  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment
  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment
  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment
Place of Origin Wuxi,China
Brand Name Trump
Certification ISO SGS
Model Number 301
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Waterproof Wooden Pallet,Standard Export Package
Delivery Time 10-15working days
Payment Terms L/C, T/T, Western Union
Supply Ability 5000Tons per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Electrical Equipment Standard JIS, AISI, ASTM, GB, DIN, EN
Material 201/304/304L/316/316L/430 Length 1000-6000mm
Width 1000-3000mm Thickness 0.1-10mm
Technique Cold Rolled Hardness ANN
High Light

stainless steel sheet metal

,

mild steel sheet
Leave a Message
Product Description



Type 301 is an austenitic stainless steel with a nominal composition of 17 percent chromium and 7 percent nickel, which provides good strength and ductility when cold worked. It also has excellent corrosion resistance properties. 301 is well suited to welding, forming and drawing. This high strength grade of steel is available in several conditions or tempers. United Performance Metals also supplies 301 in its Full Hard, 1/2 Hard and 1/4 Hard conditions.



Product Description





Item 301 Stainless Steel Sheet For Commercial Kitchen
Standard ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
Material 201,202, 304,304L,316, 316L,310S,310,309,309S, 317,317L,321,347H, 301, 405,410,420,430,etc
Surface 2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror ,checkered,embossed,hair line,brush,etching,etc
Design Diamond type, Bean type, "T"type, Chrysanthemum type or as required..
Thickness 1~10mm
Width 1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,3000mm,3500mm, as customer request
Length 2000mm,2440mm,3000mm,5800mm,6000mm,8000mm,as customer request
Package Standard export package,or as required.
Application Stainless steel checkered plate are widely used as floor,ramp,pedal,ship deck,and car plate.
Contact

If you have any question,please feel free to contact me .

We are sure your inquiry or requirements will get prompt attention



Datasheet for Stainless steel



Grade C Mn Si P S Cr Mo Ni N
201 .15 Max 5.5 - 7.5 1.00 Max .060 Max .030 Max 16 - 18   3.5 -5.5 .25 Max
202 .15 Max 5.5 - 7.5 1.00 Max .060 Max .030 Max 16 - 18   3.5 -5.5 .25 Max
301 0.15 max 2.00 max 1.00 max 0.045 max 0.030 max 16-18   6–8 0.10
302 0.15 2.00 max 0.75 0.05 0.03 17–19 - 8–10 0.10
302B 0.15 2.00 max 2.0–3.0 0.05 0.03 17–19 - 8–10 -
304 0.08 2.00 max 0.75 0.05 0.03 18-20 - 8-10.5 0.10
304L 0.03 2.00 max 0.75 0.05 0.03 18-20   6–12 0.10
304H 0.04-0.01 2.00 max 0.75 0.05 0.03 18-20   8-10.5 -
310 0.25 2.00 max 1.50 0.05 0.03 24-26 - 19-22 -
310S 0.08 2.00 max 1.50 0.05 0.03 24-26 - 19-22 -
316 0.08 2.00 max 0.75 0.05 0.03 16-15 2–3 10–14 0.10
316L 0.03 2.00 max 0.75 0.05 0.03 16-18 2–3 10–14 0.10
321 0.08 2.00 max 0.75 0.05 0.03 17–19   9–12 0.10
410 .080 -.150 1.00 max 1.00 Max 0.04 0.030 max 11.5-13.5   0.75max
  •

  •

  • Company Information

    Wuxi Trump Special Steel Co., Ltd with good reputation, high-quality products, solid strength and lower price is famous in the country. Our company has rich experience in trading as we are engaged in domestic trading for more than ten years.
    Our company is the collection of processing and operating. And we have a high supply ability.Our main products are stainless steel, galvanized steel, carbon steel and etc. These products apply to engineering, coal mine, textile, electric power, boiler, machinery, military industry and other fields.

  •



    Products' Photos



    Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment 0
  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment 1
  • Polished Stainless Steel Flat Plate ISO SGS Certification For Electrical Equipment 2

  • FAQ

  • cheap stainless steel sheet

    1. Q: are you a factory or a trading company?

    A: We are a factory with 20 years of experience, specializing in the production of stainless steel belt, stainless steel plate, good quality, competitive price, thoughtful service.

    2. Q: what is the minimum order quantity?

    A: Generally speaking, the minimum order quantity per yard is 5 metric tons. If your quantity is small, we can supply it from stock.

    3. Q: I need samples. Can you support me?

    A: We can provide you samples free of charge, but the cost of delivery is borne by our customers. To avoid misunderstandings, please provide an international express account for receipt. You can also come to visit us.

    4. Q: how to understand quality assurance?

    A: We have ISO900 certification, and 20 years of stainless steel production experience, as well as a set of quality inspection system, our product qualification rate of 99.5%.

  •
